PLAFOMETAL-OC-120

Single-skin cellular open cell ceiling with Square Mono grid

Ideal for :

Technical rooms, retail spaces

PLAFOMETAL-OC-120 is a cellular ceiling system concealing the plenum while allowing air and light to circulate. The Square Mono grid panels are compatible with traditional T grids that remain exposed and are easily removable for plenum access. They can occasionally be used in a conventional ceiling as low luminance diffusers, lighting valances, or ventilation grilles.

Selection guide

  • Active fire protection

The advantages of the system

  • Aesthetic: conceals the plenum in an indirect view while maintaining a sense of space and light.
  • Safety: significant open area for active fire protection networks
  • Installation: easy and quick installation like a traditional modular panel on T grid
  • Access: very easy through simple lifting

Description

  • Cellular ceiling made up of open cell grid panels placed on a traditional T grid system
  • The panel consists of flat vertical aluminum elements (single skin) forming a square openwork mesh
  • Compatible with all T24 and T15 grids which remain exposed
  • Possible on T15 with reveal where the grid is recessed compared to the panel
  • Access to plenum by simply lifting the panel in the grid
  • Can occasionally be used in a conventional ceiling as low luminance diffusers, lighting valances or ventilation grilles

Bulk cut

On T15 or T24 grid. Dimensions in mm.

Downloadable documents

Choose the documents you want to download

Appearance

  • Mesh

    Square mesh with a pitch of 33 mm
    Element dimensions: width 0.6 x height 20 mm

    Width 0.6 <br>Mesh 33 x 33
    Width 0.6 Mesh 33 x 33
    Element dimensions: 0.6 x 20 mm
    Mesh dimensions: 33 x 33 mm
    Aluminum: 0.7 kg/m²
    Void ratio: ≈ 96%
    Compatible with active fire protection
    Width 0.6 <br>Mesh 33 x 33
    Width 0.6
    Mesh 33 x 33
    Element dimensions: 0.6 x 20 mm
    Mesh dimensions: 33 x 33 mm
    Aluminum: 0.7 kg/m²
    Void ratio: ≈ 96%
    Compatible with active fire protection

  • Colors

    Pre-painted polyester aluminum

    • Standard White (RAL 9003)
    • Black (RAL 9005)
    • Other shades according to quantity

    Refer to the paragraph Materials and coatings on the "Metal ceiling finishes" page for more details.

    Precoated <br>White 9003
    Precoated White 9003
    Material: Aluminum
    Coating: Precoated polyester 18 µm
    Color: White RAL 9003
    Gloss: 30 UB ±5
    Precoated <br>White 9003
    Precoated
    White 9003
    Material: Aluminum
    Coating: Precoated polyester 18 µm
    Color: White RAL 9003
    Gloss: 30 UB ±5
    Precoated <br> Dark Black 9005
    Precoated
    Dark Black 9005
    Material: Aluminum
    Coating: Pre-painted polyester 18 µm
    Color: Dark black RAL 9005
    Gloss: 20 UB ±5

Performance

  • Light reflection

    Non

  • Indoor air quality

    Class A+

  • Corrosion resistance

    Ceiling indoors according to standard EN 13964

    • Class B with standard steel T grid
    • Class C with Class C or higher steel T grid
    • Suspensions and fixings to supports must be selected according to the desired class

    Refer to the Implementation page in the Products Catalog Annex for more details.

  • Cleanability

    By nature, our metal ceilings require little maintenance. However, different types of cleaning are still possible. Refer to the Maintenance page in the Product Catalog annex for more details.

  • Reservations, integrations

    No

  • Opening

    Access to the plenum by lifting the panel in the grid.

  • Resistance to disinfection chemicals

    Our metal ceilings are resistant to 2.5% sodium hypochlorite, 6% hydrogen peroxide, or 70% ethanol disinfectants (according to EN 12720 and ISO 11998 standards).Refer to the Maintenance page in the Product Catalog annexes for more details.

  • Active fire protection

    According to standard EN 12845:

    • If sprinklers are installed above the open-cell suspended ceiling, the total open flat surface area, including lighting fixtures, must not be less than 70% of the flat area.
    • In practice, a void percentage of over 80% is commonly requested for ceiling elements.

      • Vacant ceiling space percentage:

    • Over 95% for the 33 x 33 mm mesh
    • For other meshes, please contact us

  • Reaction to fire

    Euroclass A1

Technical properties

General presentation of the system family

Family : Plafonds résilles

Ideal for commercial spaces, creating light effects and airy spaces.

Aesthetics:

  • Linear or square appearance (SQUARE or GRILAM)
  • Cellular ceiling concealing the plenum from indirect view while allowing air and light circulation
  • Invisible framework blending in with the elements of the grilles
  • Wide range of mesh sizes and colors

    • Practicality:

  • Systems on T-grid or with integrated framing
  • Allows active fire protection systems to operate through the ceiling
  • Custom manufacturing of personalized grilles and accessories

Sub-family : Grille cellulaire SQUARE

Cellular cell

Open cell systems with square cells SQUARE

  • Square meshes
  • Double-skin or single-skin grids
  • Suspension on T grids or integrated grids

The products making up this system

Square Mono

Single skin cellular cell for T15 or T24
