PLAFOMETAL-OC-130

Double-skin cellular open cell ceiling with Square I grid

Ideal for :

The shops of commercial surfacesPLAFOMETAL-OC-130 is a cellular ceiling system that conceals the plenum in an indirect view while allowing air and light circulation. The Square I panels are hooked onto an integrated invisible grid that blends in with the grille elements.

Selection guide

  • Active fire protection

The advantages of the system

  • Aesthetic: The integrated grid blends with the panel and offers a choice of ceiling color (depending on quantity). The whole system conceals the plenum from indirect view while maintaining the impression of space and light.
  • Safety: significant open area for active fire protection systems.
  • Convenient: grid and panels delivered in kit form.

Description

  • Cellular ceiling consisting of grid panels laid on an integrated grid system
  • The panel is made up of vertical U-shaped aluminum elements (double skin) forming a square openwork mesh and equipped with hooks at their ends
  • The grid structure is made with the same U-shaped elements as the grid panels and provided with notches to hook the panels
  • The combination of grid structure and panels of the same material allows for a choice of ceiling color according to quantity

Bulk cut

On integrated grid. Dimensions in mm.

Downloadable documents

Choose the documents you want to download

Appearance

  • Mesh

    Mesh open cells
    Square or rectangular meshes with pitches of 50, 60, 75, 86, 100, 120, 150, or 200 mm
    Dimension of U elements:- Square i5: width 5 x height 43 mm- Square i9: width 9 x height 40 mm

    Width 5 <br>Mesh 50 x 50
    Width 5 Mesh 50 x 50
    Element dimensions: 5 x 40 mm
    Mesh dimensions: 50 x 50 mm
    Aluminum: 3.9 kg/m²
    Void ratio: ≈ 81%
    Compatible with active fire protection
    Width 5 <br>Mesh 50 x 50
    Width 5
    Mesh 50 x 50
    Element dimensions: 5 x 40 mm
    Mesh dimensions: 50 x 50 mm
    Aluminum: 3.9 kg/m²
    Void ratio: ≈ 81%
    Compatible with active fire protection
    Width 5 <br>Grid 60 x 60
    Width 5
    Grid 60 x 60
    Element dimensions: 5 x 40 mm
    Mesh dimensions: 60 x 60 mm
    Aluminum: 3.3 kg/m²
    Void rate: ≈ 84%
    Compatible with active fire protection
    Width 5 <br> Mesh 75 x 75
    Width 5
    Mesh 75 x 75
    Element dimensions: 5 x 40 mm
    Mesh dimensions: 75 x 75 mm
    Aluminium: 2.6 kg/m²
    Void ratio: ≈ 87%
    Compatible with active fire protection
    Width 5 <br>Mesh 86 x 86
    Width 5
    Mesh 86 x 86
    Element dimensions: 5 x 40 mm
    Mesh dimensions: 86 x 86 mm
    Aluminum: 2.3 kg/m²
    Void ratio: ≈ 89%
    Compatible with active fire protection
    Width 5 <br>Mesh 100 x 100
    Width 5
    Mesh 100 x 100
    Element dimensions: 5 x 40 mm
    Mesh dimensions: 100 x 100 mm
    Aluminum: 2 kg/m²
    Void ratio: ≈ 90%
    Compatible with active fire protection
    Width 5 <br> Mesh 120 x 120
    Width 5
    Mesh 120 x 120
    Elem. dim.: 5 x 40 mm
    Mesh dimensions: 120 x 120 mm
    Aluminum: 1.7 kg/m²
    Vacuum rate: ≈ 92%
    Compatible with active fire protection
    Width 5 <br> Grid 150 x 150
    Width 5
    Grid 150 x 150
    Element dimensions: 5 x 40 mm
    Mesh dimensions: 150 x 150 mm
    Aluminum: 1.3 kg/m²
    Void rate: ≈ 93%
    Compatible with active fire protection
    Width 5 <br>Grid 200 x 200
    Width 5
    Grid 200 x 200
    Element dimensions: 5 x 40 mm
    Mesh dimensions: 200 x 200 mm
    Aluminum: 1 kg/m²
    Void ratio: ≈ 95%
    Compatible with active fire protection
    Width 9 <br>Mesh 50 x 50
    Width 9
    Mesh 50 x 50
    Element dimensions: 9 x 40 mmMesh dimensions: 50 x 50 mmAluminum: 3.9 kg/m²Void ratio: ≈ 67%
    Width 9 <br>Mesh 60 x 60
    Width 9
    Mesh 60 x 60
    Dim. elements: 9 x 40 mm
    Mesh dimensions: 60 x 60 mm
    Aluminum: 3.3 kg/m²
    Void rate: ≈ 72%
    Compatible with active fire protection
    Width 9 <br>Mesh 75 x 75
    Width 9
    Mesh 75 x 75
    Element dimensions: 9 x 40 mm
    Mesh dimensions: 75 x 75 mm
    Aluminum: 2.6 kg/m²
    Void ratio: ≈ 77%
    Compatible with active fire protection
    Width 9 <br> Mesh 86 x 86
    Width 9
    Mesh 86 x 86
    Dim. elements: 9 x 40 mm
    Mesh dimensions: 86 x 86 mm
    Aluminum: 2.3 kg/m²
    Void rate: ≈ 80%
    Compatible with active fire protection
    Width 9 <br>Mesh 100 x 100
    Width 9
    Mesh 100 x 100
    Element dimensions: 9 x 40 mm
    Mesh dimensions: 100 x 100 mm
    Aluminum: 2 kg/m²
    Void ratio: ≈ 83%
    Compatible with active fire protection
    Width 9 <br>Mesh 120 x 120
    Width 9
    Mesh 120 x 120
    Dim. elements: 9 x 40 mm
    Mesh dimensions: 120 x 120 mm
    Aluminum: 1.7 kg/m²
    Vacancy rate: ≈ 86%
    Compatible with active fire protection
    Width 9 <br>Mesh 150 x 150
    Width 9
    Mesh 150 x 150
    Element dimensions: 9 x 40 mm
    Mesh dimensions: 150 x 150 mm
    Aluminum: 1.3 kg/m²
    Void ratio: ≈ 88%
    Compatible with active fire protection
    Width 9 <br>Mesh 200 x 200
    Width 9
    Mesh 200 x 200
    Element dimensions: 9 x 40 mm
    Mesh dimensions: 200 x 200 mm
    Aluminum: 1 kg/m²
    Vacuum rate: ≈ 91%
    Compatible with active fire protection

  • Colors

    Precoated polyester aluminium

    • Standard White (RAL 9003)
    • Metallic Grey (RAL 9006)
    • Black (RAL 9005)
    • Other shades available depending on quantity

    Please refer to the paragraph Materials and coatings on the "Metal Ceiling Finishes" page for more details.

    Precoated <br>White 9003
    Precoated White 9003
    Material: Aluminum
    Coating: Precoated polyester 18 µm
    Color: White RAL 9003
    Gloss: 30 UB ±5
    Precoated <br>White 9003
    Precoated
    White 9003
    Material: Aluminum
    Coating: Precoated polyester 18 µm
    Color: White RAL 9003
    Gloss: 30 UB ±5
    Pre-painted <br>Grey 9006
    Pre-painted
    Grey 9006
    Material: Aluminum
    Coating: Precoated polyester 18 μm
    Color: Metallic Grey RAL 9006
    Gloss: 30 UB ±5
    Precoated <br> Dark Black 9005
    Precoated
    Dark Black 9005
    Material: Aluminum
    Coating: Pre-painted polyester 18 µm
    Color: Dark black RAL 9005
    Gloss: 20 UB ±5

Performance

  • Light reflection

    No

  • Indoor air quality

    Class A+

  • Corrosion resistance

    Ceiling indoors according to standard EN 13964

    • Class C
    • Suspension and fastening to supports are to be selected according to the intended class

    Refer to the Implementation page in the Product Catalog Annexes for more details.

  • Cleanability

    By nature, our metal ceilings require minimal maintenance. However, various types of cleaning are possible. Please refer to the [Maintenance](https://www.plafometal.fr/conditionnement-mise-en-oeuvre-maintenance-an…) page in the Product Catalog annex for more details.

  • Reservations, integrations

    Recessed supports for spotlights, sprinklers, or other fixtures available on request.

  • Opening

    Upward panel detachment for occasional access to the plenum.

  • Resistance to disinfection chemicals

    Our metal ceilings are resistant to sodium hypochlorite 2.5%, hydrogen peroxide 6%, or ethanol 70% disinfectants (according to EN 12720 and ISO 11998 standards).Refer to the Maintenance page in the Product Catalog Annexes for more details.

  • Active fire protection

    For percentage of empty space according to the widths of U elements and mesh dimensions, please contact us.

  • Reaction to fire

    Euroclass A1

Technical properties

General presentation of the system family

Family : Plafonds résilles

Ideal for commercial spaces, creating plays of light and airy spaces

Aesthetic:

  • Ceiling with open cells hiding the plenum from indirect view while allowing air and light to circulate
  • Square (SQUARE) or linear (GRILAM) appearance
  • Invisible structure blending with grille elements
  • Wide selection of mesh sizes and colors

Practical:

  • Systems on T-grid or with integrated framework
  • Allows active fire protection networks to operate through the ceiling
  • Custom manufacturing of personalized grids and accessories

Sub-family : Grille cellulaire SQUARE

Cellular grid

Open cell systems with square SQUARE cells

  • Square meshes
  • Double-skin or single-skin grids
  • Suspension on T grids or integrated grids

The products making up this system

Square i

Double skin cellular cell with integrated grids system

Discover
